| 比較項目 | ||||||
|---|---|---|---|---|---|---|
| KW | 20 | T | 65 | A | 01 | |
| (1) | (2) | (3) | (4) | (5) | (6) | |
| (1) Piezoelectric Ceramic (2) Diameter of of plate (3) Material identification T-brass G-stainless steel N-nickel alloy B-tinplate (4) Appropriate oscillating frequency, unit : 100HZ (5) For electrode driving：A-External Drive Type B- Self Drive Type (6) Special requirement |
||||||
| 比較項目 | ||||||
|---|---|---|---|---|---|---|
 |
| 比較項目 | ||||||
|---|---|---|---|---|---|---|
| model | Resonant Frequency(KHz) | Resonant Impedance(max. Ω) | Capacitance(pF) | Plate | dimension | |
| D | T | |||||
| KW9T14A05 | 14.0±0.8 | 1000 | 3500 | Brass | 9 | 0.22 |
